XTENDEX® ST-C6USBHE-HDBT

(Remote and Local Unit)

  • Supports one local monitor and one remote monitor.
  • Local and remote units are connected via CAT5e cable
  • Supports resolutions to 1280x1024 at 590 feet
  • For best results, use low-skew CAT5e cable
  • Audio can be heard both locally and remotely
  • Connectors: 15-pin HD (video), 3.5mm audio jack/plug
  • Dimensions WxDxH (in)
  • Local unit: 3.94x2.56x1 (100x65x25.5 mm)
  • Remote unit: 3.21x1.69x0.91 (81.5x43x23 mm)
  • Power for local and remote unit: 5V DC via AC adapter
